Long Range Top Loading Arm Electrically Heated with Rigid Vapour Recovery | Model 2902-TRC

The Long Range Electrically Heated Top Loading Arm with Rigid Vapour Recovery is engineered for the safe and efficient transfer of chemical products. The arm features twin pipelines for liquid filling and vapour return, along with a vapour recovery cone to prevent emissions and enhance operational safety. This makes this Top Loading Arm with Rigid Vapour Recovery ideal for applications where hazardous or volatile fluids are being handled.

The arm is equipped with Swivel Joint 2833 Seriesfour Style 40 base swivel joints and two Style 70 double swivel joints, allowing smooth horizontal and vertical movement for precise positioning. A spring balance cylinder, level sensor, and vertical drop tube are incorporated to ensure the operator is fully protected from the hot products during use, and to maintain consistent flow throughout the filling process.

Flow rates for the Long Range Electrically Heated Top Loading Arm with Rigid Vapour Recovery are as follows:

• 3″ – 35 m³/h max
• 4″ – 60 m³/h max
• 6″ – 125 m³/h max

This combination of features makes the Arm with Rigid Vapour Recovery a reliable and versatile solution for chemical loading applications, providing both safety and efficiency.

Available Sizes:
3″x 2″ / 4″ x 3″ / 6″ x 4″

Material:
Stainless Steel

Operating Conditions:
Design Pressure 10.0 Bar G
Test Pressure 15.0 Bar G

Temperature:
-15° C / +200°C

Seal Material:
PTFE

Accessories:
Locking device arm in parking position
Stand post C-4928-A Model
Double level sensors
Electronic level sensor instead pneumatic type
Insulation
NDT test (RT-PT-MT) available on request
