Engineered Delivery Nozzles

Size

Between 0.5 to 2 inches

Material

Hastelloy, Stainless Steel

Engineered Delivery Nozzles provide controlled and reliable transfer of liquids into drums, casks, barrels, and IBCs. Manual or automatic operation ensures precision, minimises spillage, and improves efficiency in high-volume or hazardous fluid handling. Suitable for corrosive chemicals, flammable products, and food-grade liquids, these nozzles can include vapour recovery and comply with ATEX or FDA requirements for enhanced safety and environmental protection.

Need something bespoke?

We can engineer to your specific requirements - today.

Delivery available worldwide

Automatic 1" Stainless Steel nozzle with a G3 vapour recovery system which ensures gas tight filling can be achieved — Automatic 1 Stainless Steel nozzle with a G3 vapour recovery system which ensures gas tight filling can be achieved

3/4" Automatic AZV Filling Nozzle, shown secured in its dedicated holster, is designed for safe, tidy, and practical storage when not in use. — 3/4 Automatic AZV Filling Nozzle, shown secured in its dedicated holster, is designed for safe, tidy, and practical storage when not in use.

1.5 Automatic Engineered Delivery Nozzle at a 35° Angle with 1.5 RJT Male Threads

Six 0.5" Manual Nozzles — Six 0.5 Manual Nozzles

1.5" AZV with Extended Lance — 1.5 AZV with Extended Lance

1.5" Automatic Nozzle with a long lance — 1.5 Automatic Nozzle with a long lance

2" Manual Nozzle with integrated Swivel Joint — 2 Manual Nozzle with integrated Swivel Joint

AZV Filling Nozzle with automatic shut off., G1" BSP thread and at a 90° angled drop tube — AZV Filling Nozzle with automatic shut off., G1 BSP thread and at a 90° angled drop tube

1.5" stainless steel nozzle with a 180° drop tube which is being used to fill containers with ethanol — 1.5 stainless steel nozzle with a 180° drop tube which is being used to fill containers with ethanol

A 1" AZV Engineered Delivery Nozzle with Nitrogen Purge and Vapour Recovery — A 1 AZV Engineered Delivery Nozzle with Nitrogen Purge and Vapour Recovery

Description

Engineered Delivery Nozzles are precision-designed for filling liquids into containers such as drums, casks, IBCs, and barrels. They offer a reliable and safe method for transferring fluids in industrial, chemical, and food-grade applications.

Manual Nozzle
The Manual Nozzle is operated via a simple trigger mechanism. Pulling the trigger opens the valve to release the liquid, while releasing it closes the valve. This provides operators with precise control over the flow, making it ideal for careful dosing or handling of hazardous fluids.

Automatic Nozzle
The Automatic Nozzle functions similarly to a petrol pump. Pulling the trigger opens the valve, and as the container fills, the nozzle senses back pressure and automatically shuts off. This reduces the risk of spillage, improves efficiency, and simplifies operations, particularly in high-volume filling environments.

Additional Features
Engineered Delivery Nozzles are compatible with a broad spectrum of fluids, including corrosive chemicals, flammable liquids, hygienic products, and food-grade materials. They conform to ATEX standards for use in potentially explosive atmospheres, and FDA-compliant materials are available on request. Optional features such as vapour recovery systems can be integrated to further enhance safety and environmental compliance.

Contact information:

Tel: +44 (0) 1763 248 650

Email: sales@ewfm.co.uk

To keep up to date with news on how we are supporting our customers, our latest blogs and new services available, keep checking in on our website throughout the year and follow us on social media.

Additional Specifications

Available Sizes:
0.5″ / 1″ / 1.5″ / 2″

Materials:
Stainless Steel / Hastelloy

End Connections:
Threaded – BSP & NPT
Flanged – ANSI & PN
Tri Clamp

Applications:
Chemical / Food and Drink / Pharmaceutical / Oil and Gas

Additional extras:
Vapour Recovery

Swivel Joint (To ease usability)

Extended Lance

Dust Cap

Signal Switches (To signal when Nozzle is in use)

Lifting Eye (Special Hook)

Sheath
