Triple Range LPG Bottom Loading Arm Station | Model 2503-BC

The Model 2503-BC Triple Range LPG Bottom Loading Arm Station Model has been engineered to deliver safe, efficient LPG transfer from road or rail tankers. Its five swivel joints provide complete vertical and horizontal movement, giving the operator precise control and easy positioning of the arm. A spring balance system ensures smooth handling throughout operation.

To safeguard both people and plant, the station incorporates a ball valve with a positive locking device for secure flow control and a safety breakaway coupling that automatically closes off in the event of unexpected vehicle movement. This significantly reduces fire hazards, minimises environmental impact, and prevents product loss.

Connections to the vehicle can be supplied as a loose flange, threaded connection, or dry break coupling depending on site preference. Each station is delivered complete with a stand post for straightforward installation.

Available Sizes:
2″ x 1.5″ / 2″ x 2″ / 3″ x 2″ / 3″ x 3″

Material:
Carbon Steel / Low Temperature Steel / Stainless Steel

Operating Pressure:
Up to 60 Bar

Seal Material:
Swivels: Buna N
Valve: PTFE

Temperature:
-40°C / +65°C

Accessories:
Flange bracket
Locking device in parking position
WECO or CUNA connector
Dry-disconnect coupler
Drain valve with dead-man function
NDT test (X-ray-LT-MT) on request
