At EWFM, we supply Swivel Joints to customers across a wide range of industries worldwide. Each application brings different challenges, from extreme temperatures and high pressures to hygiene requirements and limited installation space.
Over the years, we have developed our Swivel Joint range to meet these varied requirements. Our products help reduce stress on hoses and pipework while allowing controlled rotational movement.
Here are some examples of how our Swivel Joints support different industries and applications.
Oil and Gas: Floating Suction Units
Swivel Joints play an important role in Floating Suction Units used within bulk liquid storage tanks.
These units draw product from near the liquid surface, helping reduce the intake of sediment and water from the tank bottom.
As the liquid level rises and falls, the Floating Suction Unit must move with it. A Swivel Joint allows this movement while maintaining a sealed connection to the fixed pipework.
We have previously supplied 12″ and 16″ Swivel Joints for Floating Suction Unit applications. Larger and smaller designs are also available to suit different tank requirements.
Find out more about our solutions for the Oil and Gas industry.
Subsea: Deep-Water Installation in Brazil
Subsea installations present some of the most demanding conditions for fluid transfer equipment.
Swivel Joints used in these environments must cope with significant external pressure while helping relieve stress within the pipework.
One example involved supplying Subsea Swivel Joints for a project in Brazil, operating at a depth of 3,000 metres below sea level.
Our Subsea Swivel Joints help reduce bending during pipe-laying operations. This can minimise the risk of damage as equipment moves towards the seabed.
Specialist designs can accommodate high-pressure applications, with operating requirements assessed individually.
Specialist Applications: Compact Swivel Joints and Dark Matter Research
Not every Swivel Joint application involves conventional fluid transfer.
We have previously supplied a Compact Swivel Joint for use in a Dark Matter research application.
Projects like this demonstrate how Swivel Joints can support specialist equipment beyond traditional industrial processes.
Compact Swivel Joints are particularly useful where installation space is limited. Their reduced footprint allows rotational movement without requiring the space of a larger design.
Our Compact Swivel Joint range covers sizes from 2″ to 12″, with Carbon Steel and Stainless Steel options available.
Cryogenic Industry: Handling Extremely Cold Media
Cryogenic applications require equipment capable of operating at extremely low temperatures.
Our Cryogenic Swivel Joints support the transfer of media such as Liquefied Natural Gas (LNG), liquid nitrogen and liquid oxygen.
At these temperatures, material compatibility and seal performance become particularly important.
Specialist Stainless Steel construction and sealing arrangements help maintain reliable movement under demanding low-temperature conditions.
Our Cryogenic Swivel Joints are available in sizes from 2″ to 16″. Certain designs can operate at temperatures down to -255°C, depending on the media and specification.
Explore our Cryogenic Swivel Joint range for further information.
Food Manufacturing: Cooking Oil and Egg Custard
The Food and Drink industry requires equipment that supports efficient production while meeting strict hygiene requirements.
We have previously supplied Swivel Joints for applications involving products ranging from cooking oil to egg custard.
In these environments, the correct materials and seals are essential. Stainless Steel construction and suitable food-contact sealing materials can help meet the requirements of the process.
Swivel Joints also allow hoses and pipework to move without excessive twisting. This can be particularly useful in filling, transfer and production equipment.
Distilling: Improving Filling Nozzle Movement
Breweries and distilleries often require flexible equipment for transferring and dispensing liquids.
Swivel Joints can work alongside Engineered Delivery Nozzles to improve manoeuvrability during filling operations.
By allowing the hose to rotate behind the nozzle, the Swivel Joint helps reduce twisting and makes the equipment easier to position.
This arrangement can support more comfortable handling during repeated filling operations.
Material and seal selection also help ensure compatibility with the product being transferred.
Drilling: Hardened Carbon Steel Swivel Joints in Egypt
Drilling applications can expose equipment to demanding operating conditions.
For one project in Egypt, we supplied 3″ hardened Carbon Steel Swivel Joints.
The hardened construction provided a suitable solution for the project’s requirements.
In drilling and similar industrial applications, Swivel Joint selection may involve additional considerations. These include pressure, external loads, operating environment and potential wear.
Understanding these conditions helps determine the most suitable material, bearing arrangement and overall design.
Chemical Processing: Handling Aggressive Media
Swivel Joints also support fluid transfer operations within the Chemical industry.
Chemical applications often require careful consideration of corrosion resistance and material compatibility.
Depending on the media, Stainless Steel, Duplex, Super Duplex or specialist alloys such as Hastelloy may be suitable. PTFE-lined options can also provide additional chemical resistance.
Swivel Joints can support chemical Loading Arms, Hose Reels and articulated pipework. They allow rotational movement while helping reduce stress on connected equipment.
The correct specification depends on the chemicals involved, operating temperature, pressure and sealing requirements.
Finding the Right Swivel Joint for Your Industry
These examples demonstrate the variety of applications where Swivel Joints can provide an effective solution.
Whether the requirement involves deep-water installation, food manufacturing, cryogenic transfer or industrial drilling, selecting the correct design is essential.
Important considerations include size, material, pressure, temperature, media compatibility and the movement required within the system.
Explore our full Swivel Joint range to discover the available products and specifications.
If you have a project in mind, get in touch with the EWFM team. We can discuss your operating requirements and help identify a suitable Swivel Joint for your application.
